Main Body Dimensions
– Main Body 1237.8 x 728.5 x 70 (mm) / 48.73 x 28.68 x 2.76 (inch)
– With Stand 1237.8 x 780.6 x 309.4 (mm) / 48.73 x 30.96 x 12.18 (inch)
– Weight 31 kg / 66.14 Ibs
** ราคายังไม่รวมภาษีมูลค่าเพิ่ม **
Display Spec
| Size | 55″ |
| Resolution | 3840 X 2160 (16:9) |
| Pixel Pitch | 0.315mm |
| Color Depth | 1.07B |
| Viewing Angle | 178°(H) / 178°(V) |
| Luminance | 500cd/m2 |
| Contrast Ratio | 1,100:1 |
| Display Area | 1209.6(H) x 680.40(V) mm |
Input
| 4 X BNC | 12G-SDI A/B Channel Input, 3G-SDI C/D Channel Input |
| 1 X HDMI | HDMI Input |
Output
| 1 X BNC | 12G/3G/HD/SD SDI Output 1Ch (SDI A/B Selected channel output) |
Input Signal
| 3G SDI | 2.970Gbps |
| HD SDI | 1.485Gbps |
| SD SDI | 270Mb/s |
| HDMI | 480i/480p/576i/576p/720p/1080i/1080p/2160p |
SDI Input Signal Formats
Audio
| Audio Out | Analog Stereo (Phone Jack) |
FPGA Functions
| 3G-SDI Level A/B, Audio Level Meter Display, Blue Only, Focus Assist, Key Lock, Luma(Y’) Zone Check, Marker, Time Code Display, Waveform/Vector, SingleMode, Camera Lut. |
Closed Caption
| CC-608 ANC, CC-608 LINE 21, CC-708 |
Calibration
| TVLogic Color Calibration Utility, 3D LUT & Adjustable Gamma |
Other Functions
| REMOTE | GPI (RJ45) |
| REMOTE | TVLogic’s specification |
| USB | Firmware update by USB memory stick |
| Ethernet | Ethernet Control support |
