SMALLHD 1703 HDR 17″ PRODUCTION MONITOR

The ultimate 17-inch HDR production monitor, featuring a 1000-nit daylight-viewable display and a rugged aluminum chassis for precise monitoring in any environment.

165,000 ฿

Pre Order

Pre Order

SKU: SMHD-1703-HDR-17 Categories: , Tags: ,

สินค้าที่นิยมซื้อไปใช้พร้อมกัน

You may also like…

Description

SmallHD 1703 HDR 17″ Production Monitor

– Dimensions 11.5 x 17.5 x 2.5″ / 292 x 445 x 64 mm
– Weight 12.1 lb / 5.5 kg

** ราคายังไม่รวมภาษีมูลค่าเพิ่ม **

SmallHD 1703 HDR 17″ Production Monitor

SmallHD 1703 HDR 17″ Production Monitor

PRODUCT HIGHLIGHTS

  • 17″, 1920×1080 Display
  • HDR Preview
  • SDI and HDMI Inputs
  • Bright 1000 cd/m² Panel
  • Colorflow 3D LUT Processing
  • 8-Bit Color Intelligence Engine
  • Page Builder OS
  • RapidRail Shoe-Mount System
  • Aluminum Construction



Display

  • Panel Type: IPS

  • Screen Size: 17″ / 43 cm

  • Resolution: 1920 x 1080

  • Pixel Density: 128 PPI

  • Aspect Ratio: 16:9

  • Active Area: 15 x 8.42

  • Brightness: 1000 cd/m²

  • Contrast Ratio: 600:1

  • Color Gamut: 100% REC709

  • Bit Depth: 8-bit

  • Viewing Angle: Left/Right: 70°, Up: 50°, Down: 70°

  • Backlight Type: LED (adjustable)



SmallHD 1703 Specs

Video I/O
Inputs 2 x SDI, 1 x HDMI
Outputs 2 x SDI, 1 x HDMI
Audio HDMI and SDI embedded
Input Formats
SDI 8-bit YCC 4:2:2
• 1080p : 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60
• 1080PsF : 23.98 / 24 / 25 / 29.97 / 30
• 1080i : 50 / 59.94 / 60 (High-speed: 100 / 119.88 / 120)
• 720p : 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60
HDMI 8-bit YCC 4:2:2, 8/10/12-bit RGB and YCC 4:4:4
• 1080p : 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60
• 1080PsF : 23.98 / 24 / 25 / 29.97 / 30
• 1080i : 50 / 59.94 / 60 (High-speed: 100 / 119.88 / 120)
• 720p : 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60
• 576p : 50 (High-speed: 100)
• 480p : 59.94 / 60 (High-speed: 119.88 / 120)
Output Formats
SDI 8-bit YCC 4:2:2 (Formats same as input)
HDMI 8-bit YCC 4:2:2, 8-bit RGB and YCC 4:4:4 (Formats same as input)
General & Data I/O
Data I/O 1 x SD Card Slot (for LUTs, Images, Firmware)
Power Inputs 1 x IEC AC Input, 1 x 4-pin XLR
Power Outputs 1 x 12 VDC LEMO, 3 x USB (0.5 A max output)

Camera Maker ตัวแทนนำเข้าและจัดจำหน่ายในประเทศไทยอย่างเป็นทางการ
ติดต่อ Line ID :@cameramaker
