| Lens Mount | RF Mount | Lens | Yes |
| Sensor | 35mm full-frame CMOS sensor | SDI Out | Yes (BNC terminal x1, 12G/6G/3G/HD-SDI) |
| Number of Pixels | Total pixels: approx. 26.7 megapixels
Effective pixels: up to approx. 19 megapixels | MON. | Yes (BNC terminal x1, 3G/HD-SDI） |
| ISO Sensitivity | 160-25600 (Extended: 100-102400) | HDMI | Type-A |
| BASE ISO | 800 / 3200 / 12800 / Auto-change (Ex.: Canon Log 2, Canon Log 3, RAW recording) | INPUT | Mini-XLR x2 (AES/EBU not supported) |
| Sensor Mode | Full-frame, Super 35mm Crop, Super 16mm Crop | Ethernet | Yes |
| ND filter | Mechanical ND filter (2 / 4 / 6 / 8* / 10 stops*）*With extender | USB | USB Type-C, for smartphone connection |
| Gamma | Canon Log ２, Canon Log 3, Canon 709, BT.709 Wide DR, BT.709 Standard, PQ, HLG | VIDEO | USB Type-C*1, for LCD connection |
| Frame Rate | 6K 59.94P/50.00P (RAW)
4.3K 59.94P/50.00P(RAW)
4K 59.94P/50.00P (RAW/XF-AVC/XF-HEVC S/XF-AVC S)
2K 59.94P/50.00P (RAW/XF-AVC/XF-HEVC S/XF-AVC S) | GRIP | USB Type-C*1, for grip connection |
| Color Space | Cinema Gamut, BT.2020 Gamut, BT.709 Gamut | MIC | Φ3.5mm stereo mini jack |
| White Balance | Auto, sunlight, tungsten, color temperature (2000K to 15000K), settings A/B | Headphone | Yes (stereo) |
| Dynamic Range | 16 stops | REMOTE A (φ2.5mm) | Yes (REMOTE terminal) |
| AF | Dual Pixel CMOS AF II | REMOTE B (RS- 422) | No |
| Recording format | Movies | Cinema RAW Light
XF-AVC
XF-HEVC S
XF-AVC S | TC (TIME CODE) | Yes (DIN terminal) |
| Photos | JPEG | G-LOCK | Yes (DIN terminal)*2 |
Maximum frame rate* (slow & fast, etc.) *When frame rate exceeds 100P in Super 35mm mode, the angle of view is cropped at approx. 6%. | Full-frame 6000×3164/60P
Super35mm Crop 4368×2304/100P, 4096×2160/120P
Super16mm Crop 2184×1152/180P | SYNC | Yes (DIN terminal)*2 |
| Recording Format (audio) | Linear PCM 24-bit/48kHz/4ch
AAC 16-bit/48kHz/2ch (XF-HEVC S / XF-AVC S) | RET | Yes (DIN terminal)*2 |
| LCD Monitor | 3.5-inch LCD 2.76 million dots, touch panel | DC-IN 12V | XLR (4-pin) |
| Viewfinder | No | Battery | BP-A30N, BP-A60N |
| Multi-Function Shoe (21 pin) | Yes (with power contacts) | Operating Temperature | Guaranteed performance conditions: Approx. 0 ℃ to 40 ℃ 85％ (relative humidity)Guaranteed operating conditions: Approx. -5 ℃ to 45 ℃ 60％(relative humidity) |
| Wi-Fi | Internal | Dimensions (W x H x D) | approx. 142 x 135 x 135mm |
| | Main body weight | approx. 1540g |
